MAGNET GPS Station - Photo by Geoff Blewitt

Station ID : S058

Station operator information from: RINEX headers

When using products from this system please cite Blewitt et al., (2018) for the processing plus also the citation for the original data.

Coordinates:

Latitude: 38.364 degrees

Longitude: 141.435 degrees

Height: 73.273 meters


Time Series Data

(ascii text)
24 Hour Final Solutions

IGS14

tenv3 or tenv

xyz

OK

tenv3

PA

tenv3

24 Hour Rapid Solutions

IGS14

tenv3

OK

tenv3

PA

tenv3

5 Minute Final Solutions

IGS14

kenv tar files for download

5 Minute Rapid Solutions
(last 60 days max)

IGS14

kenv tar file download

Quality Assurance (QA) Files

IGS14

.qa.gz file download

5 Minute Troposphere Solutions

Tot./Wet Zenith Delay, etc.

tar file download

New!: Loading Predictions.
See this README file for explanation.

IGS14

tenv3 file with extra columns

Readme Files:

tenv3 format, tenv format, xyz format,
kenv format, trop format, QA file format,
Loading triplet enhanced tenv3 files
(Note: When using the MIDAS software
use the .tenv files linked above)


Nearest 4 Other Stations Distance

J550

9.06 km

X071

9.47 km

9071

9.47 km

J036

9.47 km


Time Series Plots

Click on the buttons on the left below to choose from available reference frames, latencies, and sample rates. Original, Cleaned (outlier removed) and detrended (using MIDAS rate) plots are available. See plot explanation page for further explanations on plot contents.

GPS time series plot
GPS time series plot
GPS time series plot
GPS time series plot
GPS time series plot
GPS time series plot
GPS time series plot
GPS time series plot
QA plot
Load prediction plot


Steps Information for this station

Station ID Date
(YYMMMDD)
Equipment Change Type/
or Event ID
Earthquake
Magnitude
Distance
(km)
S05813APR17 usb000g940 5.9 21.0
S05813MAY18 usb000gy67 6.0 69.6
S05813MAY24 usb000h4jh 8.3 2040.0
S05813AUG04 usb000iv4w 5.8 40.9
S05813OCT25 usc000kn4n 7.1 313.8
S05814JUL11 usb000rs50 6.5 175.7
S05814DEC20 usc000t8p4 5.9 107.5
S05815FEB16 usb000tpvj 6.7 207.5
S05815MAY12 us20002et4 6.8 79.5
S05816APR20 us20005k66 5.9 64.7
S05816NOV11 us1000770m 6.1 18.7
S05816NOV21 us10007b88 6.9 108.1
S05816NOV23 us10007bwb 5.9 128.3
S05817FEB28 us20008mw4 5.7 89.1
S05817JUL20 us20009yb7 5.8 106.2
S05818FEB25 us2000d7pu 5.6 89.2
S05818OCT25 us1000hh6r 5.7 31.0
S05819JUN18 us600042fx 6.4 173.1
S05819AUG04 us600050if 6.3 68.8
S05820APR19 us7000903m 6.3 77.1
S05820SEP12 us7000bm9m 6.1 82.4
S05821FEB13 us6000dher 7.1 76.9
S05821MAR20 us7000dl6y 7.0 20.9
S05821APR18 us6000e2hf 5.6 45.0
S05821APR18 us6000e2hq 5.6 40.9
S05821MAY01 us7000dz5t 6.9 23.1
S05821MAY13 us7000e2xd 6.0 79.4
S05822MAR16 us6000h518 6.0 82.5
S05822MAR16 us6000h519 7.3 73.5
S05822MAR16 us6000h53e 5.5 72.1
S05823SEP18 us7000kwis 5.5 26.3
S05824JAN01 us6000m0xl 7.5 378.0
Distance is from this station to earthquake epicenter in km. A potential step record appears when this distance is less than 10^(M/2 - 0.79) where M is earthquake magnitude.
Steps for all stations are given in the master step file database.
