MAGNET GPS Station - Photo by Geoff Blewitt

Station ID : PYGR

Station operator information from: RINEX headers

When using products from this system please cite Blewitt et al., (2018) for the processing plus also the citation for the original data.

Coordinates:

Latitude: -46.166 degrees

Longitude: 166.681 degrees

Height: 253.137 meters


Time Series Data

(ascii text)
24 Hour Final Solutions

IGS14

tenv3 or tenv

xyz

AU

tenv3

PA

tenv3

24 Hour Rapid Solutions

IGS14

tenv3

AU

tenv3

PA

tenv3

5 Minute Final Solutions

IGS14

kenv tar files for download

5 Minute Rapid Solutions
(last 60 days max)

IGS14

kenv tar file download

Quality Assurance (QA) Files

IGS14

.qa.gz file download

5 Minute Troposphere Solutions

Tot./Wet Zenith Delay, etc.

tar file download

Readme Files:

tenv3 format, tenv format, xyz format,
kenv format, trop format, QA file format
(Note: When using the MIDAS software
use the .tenv files linked above)


Nearest 4 Other Stations Distance

RLTN

53.18 km

SCTY

102.37 km

BLUF

132.10 km

MAVL

142.61 km


Time Series Plots

Click on the buttons on the left below to choose from available reference frames, latencies, and sample rates. Original, Cleaned (outlier removed) and detrended (using MIDAS rate) plots are available. See plot explanation page for further explanations on plot contents.

GPS time series plot
GPS time series plot
GPS time series plot
GPS time series plot
GPS time series plot
GPS time series plot
GPS time series plot
GPS time series plot
QA plot


Steps Information for this station

Station ID Date
(YYMMMDD)
Equipment Change Type/
or Event ID
Earthquake
Magnitude
Distance
(km)
PYGR12APR03 Elevation_Cutoff_Changed - -
PYGR15SEP03 Elevation_Cutoff_Changed - -
PYGR16APR19 Antenna_Code_Changed - -
PYGR19OCT03 Antenna_Code_Changed - -
PYGR07SEP30 usp000fpgq 7.4 395.0
PYGR07OCT15 usp000fqks 6.8 166.8
PYGR07OCT15 usp000fqmj 6.1 164.3
PYGR09JUL15 usp000gz8j 7.8 45.9
PYGR09JUL15 usp000gz8p 5.7 59.1
PYGR09JUL16 usp000gzbe 5.7 42.5
PYGR09AUG05 usp000h004 6.1 72.6
PYGR10SEP03 usp000hk46 7.0 501.1
PYGR12JAN19 usp000jdpg 5.9 90.2
PYGR13DEC16 usc000llfs 5.8 54.1
PYGR14OCT13 usb000slgy 5.8 55.5
PYGR16NOV13 us1000778i 7.8 633.1
Distance is from this station to earthquake epicenter in km. A potential step record appears when this distance is less than 10^(M/2 - 0.79) where M is earthquake magnitude.
Steps for all stations are given in the master step file database.
