MAGNET GPS Station - Photo by Geoff Blewitt

Station ID : MAC1

Station operator information from: RINEX headers

When using products from this system please cite Blewitt et al., (2018) for the processing plus also the citation for the original data.

Coordinates:

Latitude: -54.500 degrees

Longitude: 158.936 degrees

Height: -6.802 meters


Time Series Data

(ascii text)
24 Hour Final Solutions

IGS14

tenv3 or tenv

xyz

AU

tenv3

PA

tenv3

24 Hour Rapid Solutions

IGS14

tenv3

AU

tenv3

PA

tenv3

5 Minute Final Solutions

IGS14

kenv tar files for download

5 Minute Rapid Solutions
(last 60 days max)

IGS14

kenv tar file download

Quality Assurance (QA) Files

IGS14

.qa.gz file download

5 Minute Troposphere Solutions

Tot./Wet Zenith Delay, etc.

tar file download

Readme Files:

tenv3 format, tenv format, xyz format,
kenv format, trop format, QA file format
(Note: When using the MIDAS software
use the .tenv files linked above)


Nearest 4 Other Stations Distance

MACI

0.03 km

PYGR

1075.96 km

BLUF

1098.76 km

RLTN

1123.49 km


Time Series Plots

Click on the buttons on the left below to choose from available reference frames, latencies, and sample rates. Original, Cleaned (outlier removed) and detrended (using MIDAS rate) plots are available. See plot explanation page for further explanations on plot contents.

GPS time series plot
GPS time series plot
GPS time series plot
GPS time series plot
GPS time series plot
GPS time series plot
GPS time series plot
GPS time series plot
QA plot


Steps Information for this station

Station ID Date
(YYMMMDD)
Equipment Change Type/
or Event ID
Earthquake
Magnitude
Distance
(km)
MAC195JUN27 Logfile_Changed - -
MAC199AUG26 Receiver_Make_and_Model_Changed - -
MAC101JAN04 Receiver_Make_and_Model_Changed - -
MAC105APR22 Receiver_Make_and_Model_Changed - -
MAC109MAR20 Receiver_Make_and_Model_Changed - -
MAC109MAY25 Receiver_Make_and_Model_Changed - -
MAC111APR24 Receiver_Make_and_Model_Changed - -
MAC116NOV29 Antenna_and_Radome_Codes_Changed - -
MAC116NOV29 Receiver_Make_and_Model_Changed - -
MAC198MAR25 usp0008hzd 8.1 1076.1
MAC198JUN16 usp0008pzc 6.2 178.2
MAC101MAR06 usp000ab03 6.4 107.8
MAC104FEB26 usp000cne1 6.0 156.3
MAC104DEC23 usp000db93 8.1 599.9
MAC106DEC06 usp000ezp5 5.8 57.7
MAC107SEP30 usp000fpgq 7.4 681.0
MAC108APR12 usp000g3q9 7.1 133.1
MAC109JUL15 usp000gz8j 7.8 1111.8
MAC112JUN22 usp000jn2y 5.7 18.2
MAC113MAY24 usb000h4aj 5.6 2.4
MAC116SEP08 us10006n6r 6.1 19.2
MAC119MAR01 us1000j92m 5.9 127.4
MAC119OCT01 usd000b35a 5.5 87.9
MAC120FEB05 us70007j07 5.8 16.8
MAC122MAY19 us6000hm9e 5.6 54.7
MAC122MAY19 us6000hm9j 6.9 41.6
Distance is from this station to earthquake epicenter in km. A potential step record appears when this distance is less than 10^(M/2 - 0.79) where M is earthquake magnitude.
Steps for all stations are given in the master step file database.
