MAGNET GPS Station - Photo by Geoff Blewitt

Station ID : AB06

Data attribution information: DOI Database

DOI link for this station: https://doi.org/10.7283/T5MC8X0D

Station operator information from: RINEX headers

When using products from this system please cite Blewitt et al., (2018) for the processing plus also the citation for the original data.

Coordinates:

Latitude: 54.885 degrees

Longitude: -163.423 degrees

Height: 500.412 meters


Time Series Data

(ascii text)
24 Hour Final Solutions

IGS14

tenv3 or tenv

xyz

NA

tenv3

PA

tenv3

5 Minute Final Solutions

IGS14

kenv tar files for download

Quality Assurance (QA) Files

IGS14

.qa.gz file download

5 Minute Troposphere Solutions

Tot./Wet Zenith Delay, etc.

tar file download

New!: Loading Predictions.
See this README file for explanation.

IGS14

tenv3 file with extra columns

Readme Files:

tenv3 format, tenv format, xyz format,
kenv format, trop format, QA file format,
Loading triplet enhanced tenv3 files
(Note: When using the MIDAS software
use the .tenv files linked above)


Nearest 4 Other Stations Distance

AV38

23.65 km

AV34

25.74 km

AV40

33.72 km

AV39

37.72 km


Time Series Plots

Click on the buttons on the left below to choose from available reference frames, latencies, and sample rates. Original, Cleaned (outlier removed) and detrended (using MIDAS rate) plots are available. See plot explanation page for further explanations on plot contents.

GPS time series plot
GPS time series plot
GPS time series plot
GPS time series plot
GPS time series plot
GPS time series plot
GPS time series plot
GPS time series plot
QA plot
Load prediction plot


Steps Information for this station

Station ID Date
(YYMMMDD)
Equipment Change Type/
or Event ID
Earthquake
Magnitude
Distance
(km)
AB0609AUG23 Antenna_Code_Changed - -
AB0622JUN20 Antenna_Code_Changed - -
AB0622JUN20 Receiver_Make_and_Model_Changed - -
AB0605NOV20 usp000e4j8 6.2 123.8
AB0607OCT02 usp000fpqs 6.3 117.8
AB0611MAR11 official20110311054624120_30 9.1 4398.5
AB0611JUN24 usp000j3mq 7.3 639.3
AB0611JUL16 usp000j51f 6.1 137.1
AB0611NOV06 usp000jae5 5.7 102.1
AB0614JUN23 usc000rki5 7.9 1227.1
AB0618JAN23 us2000cmy3 7.9 906.1
AB0620JUL22 us7000asvb 7.8 308.7
AB0620JUL28 us6000b56k 6.1 142.5
AB0620OCT19 us6000c9hg 7.6 245.8
AB0621JUL29 ak0219neiszm 8.2 355.9
AB0621AUG14 us6000f652 6.9 369.6
AB0622JAN11 us7000gavu 6.8 401.9
AB0623JUL16 us7000kg30 7.2 179.8
Distance is from this station to earthquake epicenter in km. A potential step record appears when this distance is less than 10^(M/2 - 0.79) where M is earthquake magnitude.
Steps for all stations are given in the master step file database.
