MAGNET GPS Station - Photo by Geoff Blewitt

Station ID : AV34

Data attribution information: DOI Database

DOI link for this station: https://doi.org/10.7283/T5V122T8

Station operator information from: RINEX headers

When using products from this system please cite Blewitt et al., (2018) for the processing plus also the citation for the original data.

Coordinates:

Latitude: 54.725 degrees

Longitude: -163.713 degrees

Height: 636.394 meters


Time Series Data

(ascii text)
24 Hour Final Solutions

IGS14

tenv3 or tenv

xyz

NA

tenv3

PA

tenv3

24 Hour Rapid Solutions

IGS14

tenv3

NA

tenv3

PA

tenv3

5 Minute Final Solutions

IGS14

kenv tar files for download

5 Minute Rapid Solutions
(last 60 days max)

IGS14

kenv tar file download

Quality Assurance (QA) Files

IGS14

.qa.gz file download

5 Minute Troposphere Solutions

Tot./Wet Zenith Delay, etc.

tar file download

New!: Loading Predictions.
See this README file for explanation.

IGS14

tenv3 file with extra columns

Readme Files:

tenv3 format, tenv format, xyz format,
kenv format, trop format, QA file format,
Loading triplet enhanced tenv3 files
(Note: When using the MIDAS software
use the .tenv files linked above)


Nearest 4 Other Stations Distance

AV40

9.14 km

AV38

12.62 km

AV37

18.34 km

AV39

20.69 km


Time Series Plots

Click on the buttons on the left below to choose from available reference frames, latencies, and sample rates. Original, Cleaned (outlier removed) and detrended (using MIDAS rate) plots are available. See plot explanation page for further explanations on plot contents.

GPS time series plot
GPS time series plot
GPS time series plot
GPS time series plot
GPS time series plot
GPS time series plot
GPS time series plot
GPS time series plot
QA plot
Load prediction plot


Steps Information for this station

Station ID Date
(YYMMMDD)
Equipment Change Type/
or Event ID
Earthquake
Magnitude
Distance
(km)
AV3409AUG09 Antenna_Code_Changed - -
AV3416JUN26 Elevation_Cutoff_Changed - -
AV3420AUG15 Receiver_Make_and_Model_Changed - -
AV3411MAR11 official20110311054624120_30 9.1 4379.4
AV3411JUN24 usp000j3mq 7.3 614.8
AV3411JUL16 usp000j51f 6.1 155.6
AV3411NOV06 usp000jae5 5.7 101.0
AV3414JUN23 usc000rki5 7.9 1206.2
AV3416OCT27 us100072bs 5.9 130.0
AV3418JAN23 us2000cmy3 7.9 928.5
AV3420JUL22 us7000asvb 7.8 329.4
AV3420JUL28 us6000b56k 6.1 161.1
AV3420OCT19 us6000c9hg 7.6 263.2
AV3421JUL29 ak0219neiszm 8.2 377.7
AV3421AUG14 us6000f652 6.9 390.7
AV3422JAN11 us7000gavu 6.8 376.2
AV3423JUL16 us7000kg30 7.2 193.8
Distance is from this station to earthquake epicenter in km. A potential step record appears when this distance is less than 10^(M/2 - 0.79) where M is earthquake magnitude.
Steps for all stations are given in the master step file database.
