MAGNET GPS Station - Photo by Geoff Blewitt

Station ID : SHEC

Station operator information from: RINEX headers

When using products from this system please cite Blewitt et al., (2018) for the processing plus also the citation for the original data.

Coordinates:

Latitude: -0.645 degrees

Longitude: -78.459 degrees

Height: 4188.236 meters


Time Series Data

(ascii text)
24 Hour Final Solutions

IGS14

tenv3 or tenv

xyz

SA

tenv3

5 Minute Final Solutions

IGS14

kenv tar files for download

Quality Assurance (QA) Files

IGS14

.qa.gz file download

5 Minute Troposphere Solutions

Tot./Wet Zenith Delay, etc.

tar file download

New!: Loading Predictions.
See this README file for explanation.

IGS14

tenv3 file with extra columns

Readme Files:

tenv3 format, tenv format, xyz format,
kenv format, trop format, QA file format,
Loading triplet enhanced tenv3 files
(Note: When using the MIDAS software
use the .tenv files linked above)


Nearest 4 Other Stations Distance

CONE

5.29 km

VCES

17.83 km

ASEC

36.01 km

QUEM

45.54 km


Time Series Plots

Click on the buttons on the left below to choose from available reference frames, latencies, and sample rates. Original, Cleaned (outlier removed) and detrended (using MIDAS rate) plots are available. See plot explanation page for further explanations on plot contents.

GPS time series plot
GPS time series plot
GPS time series plot
GPS time series plot
GPS time series plot
QA plot
Load prediction plot


Steps Information for this station

Station ID Date
(YYMMMDD)
Equipment Change Type/
or Event ID
Earthquake
Magnitude
Distance
(km)
SHEC10FEB27 official20100227063411530_30 8.8 3986.4
SHEC10AUG12 usp000hj05 7.1 145.6
SHEC12SEP30 usp000jta1 7.3 369.1
SHEC13FEB09 usc000f4ij 6.9 230.7
SHEC16APR16 us20005j32 7.8 198.7
SHEC16MAY18 us10005i5t 6.7 190.0
SHEC16MAY18 us10005i9n 6.9 180.6
SHEC16JUL11 us100062hg 6.3 189.1
SHEC19FEB22 us2000jlfv 7.5 232.1
SHEC19MAY26 us60003sc0 8.0 674.8
SHEC21NOV28 us7000fxq2 7.5 462.6
SHEC23MAR18 us7000jl3s 6.8 283.8
Distance is from this station to earthquake epicenter in km. A potential step record appears when this distance is less than 10^(M/2 - 0.79) where M is earthquake magnitude.
Steps for all stations are given in the master step file database.
