MAGNET GPS Station - Photo by Geoff Blewitt

Station ID : NOA1

Station operator information from: RINEX headers

When using products from this system please cite Blewitt et al., (2018) for the processing plus also the citation for the original data.

Coordinates:

Latitude: 38.047 degrees

Longitude: 23.864 degrees

Height: 537.817 meters


Time Series Data

(ascii text)
24 Hour Final Solutions

IGS14

env

xyz

EU

env

24 Hour Rapid Solutions

IGS14

env

EU

env

5 Minute Final Solutions

IGS14

kenv tar files for download

5 Minute Rapid Solutions
(last 60 days max)

IGS14

kenv tar file download

5 Minute Ultra Rapid Solutions
(files updated hourly)

FID

individual kenv files for download

Quality Assurance (QA) Files

IGS14

.qa.gz file download

5 Minute Troposphere Solutions

Tot./Wet Zenith Delay, etc.

tar file download

Readme Files:

env format, xyz format,
kenv format, QA file format


Nearest 4 Other Stations Distance

JGC1

5.41 km

DYNG

6.94 km

DION

6.95 km

MET0

9.13 km


Time Series Plots

Click on the buttons on the left below to choose from available reference frames, latencies, and sample rates. Original, Cleaned (outlier removed) and detrended (using MIDAS rate) plots are available. See plot explanation page for further explanations on plot contents.

GPS time series plot
GPS time series plot
GPS time series plot
GPS time series plot
GPS time series plot
GPS time series plot
GPS time series plot


Steps Information for this station

Station ID Date
(YYMMMDD)
Equipment Change Type/
or Event ID
Earthquake
Magnitude
Distance
(km)
NOA116MAR11 Elevation_Cutoff_Changed - -
NOA108JAN06 usp000fw2w 6.2 138.5
NOA108FEB14 usp000fyw4 6.9 259.3
NOA108FEB14 usp000fywh 6.5 259.3
NOA108JUN08 usp000g8vs 6.4 205.1
NOA113OCT12 usb000kbn7 6.6 286.9
NOA114MAY24 usb000r2hc 6.9 281.8
NOA118OCT25 us1000hhb1 6.8 296.0
Distance is from this station to earthquake epicenter in km. A potential step record appears when this distance is less than 10^(M/2 - 0.8) where M is earthquake magnitude.
Steps for all stations are given in the master step file database.
