MAGNET GPS Station - Photo by Geoff Blewitt

Station ID : I036

Network Operator's Station ID : 3036

Station operator information from: RINEX headers

When using products from this system please cite Blewitt et al., (2018) for the processing plus also the citation for the original data.

Coordinates:

Latitude: 35.312 degrees

Longitude: 139.826 degrees

Height: 46.733 meters


Time Series Data

(ascii text)
24 Hour Final Solutions

IGS14

tenv3 or tenv

xyz

OK

tenv3

PA

tenv3

24 Hour Rapid Solutions

IGS14

tenv3

OK

tenv3

PA

tenv3

5 Minute Final Solutions

IGS14

kenv tar files for download

5 Minute Rapid Solutions
(last 60 days max)

IGS14

kenv tar file download

Quality Assurance (QA) Files

IGS14

.qa.gz file download

5 Minute Troposphere Solutions

Tot./Wet Zenith Delay, etc.

tar file download

Readme Files:

tenv3 format, tenv format, xyz format,
kenv format, trop format, QA file format
(Note: When using the MIDAS software
use the .tenv files linked above)


Nearest 4 Other Stations Distance

I045

13.29 km

I067

15.40 km

I039

18.75 km

I032

20.86 km


Time Series Plots

Click on the buttons on the left below to choose from available reference frames, latencies, and sample rates. Original, Cleaned (outlier removed) and detrended (using MIDAS rate) plots are available. See plot explanation page for further explanations on plot contents.

GPS time series plot
GPS time series plot
GPS time series plot
GPS time series plot
GPS time series plot
GPS time series plot
GPS time series plot
GPS time series plot
QA plot


Steps Information for this station

Station ID Date
(YYMMMDD)
Equipment Change Type/
or Event ID
Earthquake
Magnitude
Distance
(km)
I03609JUN06 usp000gxx2 5.8 100.5
I03609AUG09 usp000h04j 7.1 294.6
I03609AUG10 usp000h05y 6.2 155.6
I03609AUG12 usp000h093 6.6 281.9
I03611MAR09 usp000hvhj 7.3 438.8
I03611MAR11 official20110311054624120_30 9.1 402.0
I03611MAR11 usp000hvp4 6.4 222.0
I03611MAR11 usp000hvpa 7.9 158.3
I03611MAR11 usp000hvpc 6.6 234.5
I03611MAR11 usp000hvpd 6.5 216.6
I03611MAR11 usp000hvpg 7.7 523.1
I03611MAR11 usp000hvpm 5.8 127.7
I03611MAR11 usp000hvq3 6.0 104.9
I03611MAR11 usp000hvrd 6.5 183.3
I03611MAR11 usp000hvug 5.7 108.5
I03611MAR11 usp000hvy0 6.3 194.5
I03611MAR11 usp000hw1j 5.5 86.0
I03611MAR13 usp000hwq6 6.1 170.2
I03611MAR15 usp000hxc7 6.0 112.9
I03611MAR15 usp000hxdx 5.7 106.7
I03611MAR16 usp000hxf1 5.7 93.5
I03611MAR22 usp000hy7j 5.7 107.0
I03611APR07 usp000hzf6 7.1 365.0
I03611APR11 usp000hzq8 6.6 194.8
I03611APR11 usp000hzsk 6.2 69.0
I03611APR21 usp000j0c3 6.2 52.6
I03611MAY20 usp000j1v8 5.8 104.7
I03611MAY21 usp000j1zc 5.6 68.2
I03611JUL10 usp000j4gp 7.0 430.8
I03611JUL30 usp000j5rk 6.3 207.7
I03611SEP15 usp000j82k 6.1 172.2
I03612MAR14 usp000jg80 6.0 89.1
I03612APR24 usp000jjhz 5.5 68.0
I03612APR29 usp000jjs6 5.8 57.0
I03612JUN05 usp000jmcv 6.1 125.7
I03612DEC07 usp000jwjn 7.3 466.5
I03613OCT25 usc000kn4n 7.1 479.7
I03613NOV09 usb000kvca 5.6 68.7
I03613NOV16 usb000kzuj 5.5 44.0
I03613DEC21 usc000lpah 5.5 81.5
I03615MAY30 us20002ki3 7.8 833.4
I03616SEP23 us10006rte 6.2 190.3
I03616NOV21 us10007b88 6.9 270.4
I03618JUL07 us2000fz0q 5.9 77.6
I03620JUN24 us7000aabt 5.9 114.5
I03621FEB13 us6000dher 7.1 320.1
I03621MAR20 us7000dl6y 7.0 384.9
I03621MAY01 us7000dz5t 6.9 357.8
I03621OCT07 us6000fsl6 5.9 36.6
I03622MAR16 us6000h519 7.3 309.6
Distance is from this station to earthquake epicenter in km. A potential step record appears when this distance is less than 10^(M/2 - 0.79) where M is earthquake magnitude.
Steps for all stations are given in the master step file database.
