MAGNET GPS Station - Photo by Geoff Blewitt

Station ID : G140

Network Operator's Station ID : 1140

Station operator information from: RINEX headers

When using products from this system please cite Blewitt et al., (2018) for the processing plus also the citation for the original data.

Coordinates:

Latitude: 20.426 degrees

Longitude: 136.081 degrees

Height: 47.066 meters


Time Series Data

(ascii text)
24 Hour Final Solutions

IGS14

env

xyz

PA

env

PS

env

5 Minute Final Solutions

IGS14

kenv tar files for download

Quality Assurance (QA) Files

IGS14

.qa.gz file download

5 Minute Troposphere Solutions

Tot./Wet Zenith Delay, etc.

tar file download

Readme Files:

tenv3 format, tenv format, xyz format,
kenv format, trop format, QA file format


Nearest 4 Other Stations Distance

J605

718.98 km

X086

722.11 km

J604

723.83 km

J497

779.29 km


Time Series Plots

Click on the buttons on the left below to choose from available reference frames, latencies, and sample rates. Original, Cleaned (outlier removed) and detrended (using MIDAS rate) plots are available. See plot explanation page for further explanations on plot contents.

GPS time series plot
GPS time series plot
GPS time series plot
GPS time series plot
GPS time series plot
GPS time series plot
GPS time series plot
QA plot


Steps Information for this station

Station ID Date
(YYMMMDD)
Equipment Change Type/
or Event ID
Earthquake
Magnitude
Distance
(km)
G14007SEP28 usp000fpca 7.5 705.1
G14011MAR11 official20110311054624120_30 9.1 2077.2
G14015MAY30 us20002ki3 7.8 937.8
G14016JUL29 us100068jg 7.7 1009.9
Distance is from this station to earthquake epicenter in km. A potential step record appears when this distance is less than 10^(M/2 - 0.79) where M is earthquake magnitude.
Steps for all stations are given in the master step file database.
