MAGNET GPS Station - Photo by Geoff Blewitt

Station ID : AV10

Data attribution information: DOI Database

DOI link for this station: https://doi.org/10.7283/T5KW5CZ2

Station operator information from: RINEX headers

When using products from this system please cite Blewitt et al., (2018) for the processing plus also the citation for the original data.

Coordinates:

Latitude: 54.098 degrees

Longitude: -165.934 degrees

Height: 329.521 meters


Time Series Data

(ascii text)
24 Hour Final Solutions

IGS14

tenv3 or tenv

xyz

NA

tenv3

PA

tenv3

24 Hour Rapid Solutions

IGS14

tenv3

NA

tenv3

PA

tenv3

5 Minute Final Solutions

IGS14

kenv tar files for download

5 Minute Rapid Solutions
(last 60 days max)

IGS14

kenv tar file download

Quality Assurance (QA) Files

IGS14

.qa.gz file download

5 Minute Troposphere Solutions

Tot./Wet Zenith Delay, etc.

tar file download

New!: Loading Predictions.
See this README file for explanation.

IGS14

tenv3 file with extra columns

Readme Files:

tenv3 format, tenv format, xyz format,
kenv format, trop format, QA file format,
Loading triplet enhanced tenv3 files
(Note: When using the MIDAS software
use the .tenv files linked above)


Nearest 4 Other Stations Distance

AKMO

5.19 km

AV14

6.46 km

AV13

6.60 km

AKLV

7.38 km


Time Series Plots

Click on the buttons on the left below to choose from available reference frames, latencies, and sample rates. Original, Cleaned (outlier removed) and detrended (using MIDAS rate) plots are available. See plot explanation page for further explanations on plot contents.

GPS time series plot
GPS time series plot
GPS time series plot
GPS time series plot
GPS time series plot
GPS time series plot
GPS time series plot
GPS time series plot
QA plot
Load prediction plot


Steps Information for this station

Station ID Date
(YYMMMDD)
Equipment Change Type/
or Event ID
Earthquake
Magnitude
Distance
(km)
AV1019APR02 Elevation_Cutoff_Changed - -
AV1023JUN26 Antenna_Code_Changed - -
AV1023JUN26 Receiver_Make_and_Model_Changed - -
AV1005NOV20 usp000e4j8 6.2 123.7
AV1006SEP01 usp000es7t 5.9 33.1
AV1007DEC26 usp000fvad 6.4 228.8
AV1009OCT13 usp000h2u7 6.5 165.2
AV1009OCT13 usp000h2wq 6.4 183.7
AV1010JUL18 usp000hfdm 6.7 292.4
AV1011MAR11 official20110311054624120_30 9.1 4233.0
AV1011JUN24 usp000j3mq 7.3 455.1
AV1011SEP02 usp000j7dc 6.9 440.6
AV1012AUG10 usp000jq4r 6.2 190.4
AV1014JUN23 usc000rki5 7.9 1054.3
AV1015JUL27 us200030aq 6.9 302.1
AV1018JAN23 us2000cmy3 7.9 1086.1
AV1020JUL22 us7000asvb 7.8 484.8
AV1020OCT19 us6000c9hg 7.6 412.5
AV1020DEC01 us7000clnv 6.4 213.6
AV1021JUL29 ak0219neiszm 8.2 535.1
AV1022JAN11 us7000gavu 6.8 229.9
AV1022JAN11 us7000gawk 6.6 231.9
AV1022JAN22 us7000ge5q 6.2 107.3
AV1023JUL16 us7000kg30 7.2 337.5
Distance is from this station to earthquake epicenter in km. A potential step record appears when this distance is less than 10^(M/2 - 0.79) where M is earthquake magnitude.
Steps for all stations are given in the master step file database.
